North Pro Chassis

North Pro Chassis

$0.00 USD
$0.00 USD $0.00 USD
Sale Sold out
Taxes included. Shipping calculated at checkout.
Style

North and North XL comparison

North North XL
Cooling Front radiator Up to 360 mm Up to 420/360 mm
Top radiator Up to 240 mm Up to 280/360 mm
Included Aspect 140 mm fans 2 3
Total 120 mm fan mounts 8 (Mesh)


4 (TG)

 9 (Mesh)


7 (TG)
Total 140 mm fan mounts 6 (Mesh)


4 (TG)

 8 (Mesh)


4 (TG)
Compatibility Graphics card (max length) Up to 355 mm Up to 413 mm
Motherboard ATX E-ATX (330 mm)


Specifications

  • Dedicated 2.5" drive mounts
    2
  • Combined 3.5/2.5” drive mounts
    2 included
  • 5.25” drive mounts
    0
  • Expansion slots
    7
  • Front interface
    1xUSB 3.1 Gen 2 Type-C, 2xUSB 3.0, Audio & Mic
  • Total fan mounts (TG Version)
    7 x 120 mm or 6 x 140 mm
  • Total fan mounts (Mesh Version)
    9 x 120 mm or 8 x 140 mm
  • Front fan
    3 x 120 mm, 3 x 140 mm (3 x Aspect 140mm PWM included)
  • Top fan
    3 x 120 mm, 2 x 140 mm or 2 x 180 mm
  • Rear fan
    1 x 120/140 mm
  • Dust filters
    Front, PSU
  • Fixed cable straps
    Yes
  • Cable routing grommets
    Yes
  • Captive thumbscrews
    HDD brackets, SSD bracket, Side Panels, Fan Bracket, PSU Bracket
  • Left side panel
    Mesh
  • Right side panel
    Steel

Compatibility

  • Motherboard compatibility
    E-ATX / ATX / mATX / Mini-ITX
  • Power supply type
    ATX
  • PSU max length
    1 HDD Tray: 290mm max, 2 HDD Trays: 175 mm
  • GPU max length
    413 mm with front fan mounted / 380 mm with 420/360 mm front mounted radiator
  • CPU cooler max height
    155 mm with Fan Bracket / 185 mm w.o.
  • Front radiator
    Up to 420/360 mm
  • Top radiator
    Up to 280/360 mm
  • Rear radiator
    1 x 120/140 mm
  • Cable routing space
    29 mm

Dimensions

  • Case dimensions (LxWxH)
    503 x 240 x 509 mm
  • Case dimensions w/o feet/protrusions/screws
    490 x 240 x 490 mm
  • Net weight
    9.7 kg (Mesh) / 9.5kg (TG)
  • Package dimensions (LxWxH)
    604 x 355 x 608 mm
  • Gross weight
    11.9 kg (Mesh) / 11.7kg (TG)

Other

  • Package contents (Mesh version)
    North case, Accessory Box, Fan Bracket Accessory Box, User Manual
  • Package contents (TG version)
    North case, Accessory Box, User Manual
  • EAN
    Charcoal Black: 7340172706533, Charcoal Black TGD:843276106546, Chalk White: 7340172706557, Chalk White TGC: 7340172706564
  • UPC
    Charcoal Black: 843276106539, Charcoal Black TGD: 843276104719, Chalk White: 843276106553, Chalk White TGC: 843276106560
  • JAN
    Charcoal Black: 4537694326902, Charcoal Black TGD: 4537694326919, Chalk White: 4537694326926, Chalk White TGC: 4537694326933
  • Product Code
    Charcoal Black: FD-C-NOR1X-01, Charcoal Black TGD: FD-C-NOR1X-02, Chalk White: FD-C-NOR1X-03, Chalk White TGC: FD-C-NOR1X-04
  • Warranty
    2 Years
